Connecting to an Amplifier

Make one of the following connections, depending on the capabilities of your existing equipment.

Connecting to an Amplifier via 2 Channel Audio Output

Connect the Left and Right 2CH AUDIO OUT jacks (A) on the player to the audio left and right in jacks on your amplifier,

receiver, or stereo system, using audio cables.

Connecting to an Amplifier via Digital Audio Output (Optical or Coaxial)

Connect the player’s DIGITAL AUDIO OUT (OPTICAL or COAXIAL) jack to the corresponding in jack (OPTICAL O or

COAXIAL X) on your amplifier. Use an optional dig ital (optical O or coaxial X) audio cable. You will need to activate the

unit’s digital output. (See “[Audio] Menu” on page 46.)

Amplifier/Receiver

Connecting to an Amplier via HDMI Output

Connect the unit HDMI OUT jack to the corresponding in jack on your amplier. Use a HDMI cable (H1). You will need to

activate the player’s digital output. (See “[Audio] Menu” on page 46.)

Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this you need a multi-channel Audio/Video

Receiver that supports one or more of the audio formats supported by your player. Check the receiver manual and the

logos on the front of the receiver. (LPCM, Dolby Digital, Dolby Digital Plus and DTS)

Connect the amplier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable (H2) if your amplier has

HDMI output jack.
